Features
? Green LED light source, ABBE compensation no required
? Hartman testing method, CPU high-speed precise computing
? Automatic identifying the lens type, Automatic measurement, Automatic reading and memorying the data
? 5.7 inch high resolving power LED screen
? Broad contents, strong performances, simple and convenient operation
? Latest international designing concept of collecting technology, mode and individuality
Technical Parameters
? Measuring range：
1. Sphere：0 to ±35D（0.01D/0.06D/0.12D/0.25D steps)
2. Cylinder: 0 to ±10D（0.01D/0.06D/0.12D/0.25D steps)
3. Axis: 0°to 180°（1°step)
4. ADD: 0 to 10D（0.01D/0.06D/0.12D/0.25D steps)
5. Prism: 0 to 15△(0.01△)
? Cylinder mode: +, +/-, -
? Prism mode:
o X-Y: cartesian coordinates H:I,O; V:U,D.
o P-B: polar coordinates
o mm: mm expression
? Reading resolving power： 0.01D,0.06D,0.12D,0.25D
? PD measure
? Measure single vision lens,bifocal lens,trifocal lens and progressive lens,etc
? Contact lens measure
? UV transmissivity
? Measurable transmissivity: ＞10%; ＞20% at ±10D and over
? Contact lens: 0 to ±25D, BC 6.00 to 9.00
? Display: 5.7 TFT LCD
? Menu: readable diagram, easy operation
? Lens diameter: 20mm～100mm
? Power source: AC100(±10%)～240(±10%)V, 50/60HZ, 40VA
? Power consumption: 40W
? N.Weight: 4kg
? Dimensions：190*210*420mm
? Environmental condition：
o Temperature：5℃～40℃（in usage）
-20℃～60℃（in storage/transference）
o Humidity：30～85%（non-condensing）（in usage）
10～95%（in storage/transference）
o Atmospheric pressure：700～1060hpa
o Altitud：up to 2000m
o Others: no harmful dust or smoke
? Optional accessories：printer（built-in thermosensitive paper size：57mm）
